MODULAR HI-FI - MHF SERIES

Note: Unless otherwise indicated:
All the following books are in good to excellent condition.

Sams Photofact Books are Service Manuals.
Sams Photofact Books ARE NOT Owner's Manuals.

Note: As a rule, Sams Photofact "Modular Hi-Fi" Books
Do Not contain any service information for the Record Player,
Record Changer, Tape Player, or Tape Recorder mechanisms.
Only the electronics is covered.

In some cases, a seperate Sams Photofact Service Manual for the
Record Changer, Tape Player, or Tape Recorder mechanism
was published.

However, in many cases, the manufacturer of the
electronic unit may have used more than one
make and model of a Record or Tape mechanism.

The make and model of the mechanism will need to be
determined.

Modular Hi-Fi Components Series.
Volume MHF-34 - Feb. 1973

Covers the following Makes and Models:

Arvin - AM/FM Stereo Radio/Phonos
30X76-18/50X36-19/80X76-18 (1.01141/1.01161/1.01171).

Bradford - AM/FM Stereo Receiver 59089.
Hitachi - AM/FM Stereo Receiver SR-1100.
Masterwork - AM/FM Stereo Receiver M4720.

Morse / Electrophonic - AM/FM Stereo Radio/8-Track Tape Player
T-4600.

Panasonic - AM/FM Stereo Radio/Phono SE-840.
Penncrest - AM/FM Stereo Radio/8-Track Tape Player 1702.

RCA - AM/FM Stereo Radio/8-Track Tape Player
RK335A/TCT801/VS6025.

Sony - AM/FM Stereo Receiver HST-230A.

Symphonic - AM/FM Stereo Receivers
1123B/1123G/2123/2223 (R-840/R-845).

Toyo - AM/FM Stereo Radio/8-Track Tape Player CRH-661.

Softcover 10 3/4" x 7 3/4". 128 pages.

Price: $15.00

Modular Hi-Fi Components Series.
Volume MHF-37 - May 1973

Covers the following Makes and Models:

Bell & Howell - AM/FM Stereo Receiver 3650.

Electrohome - AM/FM Stereo Receivers
Manhattan/SC420 (H18-201/H18-202).

General Electric - AM/FM Stereo Receivers
A505G/A505H/C172G/C460G/C467G/C467H/G270G/
G504G/G504H/G507G/P774G/P775G (PK170).

Hitachi - AM/FM Stereo Receiver DPK-340.

Morse / Electrophonic - AM/FM Stereo Radio/8-Track Tape Players
R-12A/T-100A/T-600A.

Panasonic - AM/FM Stereo Receiver SA-5800.
RCA - Stereo 8-Track Tape Player YZD596W.
Sears Silvertone - AM/FM Stereo Radio/Phono 548.74210000.
Sony - AM/FM Stereo Radio/Phono HP-510.

Symphonic - AM/FM Stereo Radio/Phono/8-Track Tape Players
1253/1253T.

Softcover 10 3/4" x 7 3/4". 128 pages.

Price: $16.50

Modular Hi-Fi Components Series.
Volume MHF-49 - May 1974

Covers the following Makes and Models:

Bradford - AM/FM Stereo Receiver 1453A13 (WTG79541).
H. H. Scott - AM/FM Stereo Receiver 387B.

Lafayette - AM/FM Stereo Radio/8-Track Tape Player
SQR-40 (99-02875W).

Lloyd's - AM/FM Stereo Radio/Phono/8-Track Tape Players
M638/M686/M847/M858/2D37 (2B37-37).

Magnavox - AM/FM Stereo Radio/Phono R245-01-AA.

Olympic - AM/FM Stereo Radio/Phono/8-Track Tape Players
CT836/TG8343/TG8346/TG8357/TG8376 (8336).

Panasonic - AM/FM Stereo Radio/Phonos SD-501/SE-5010.

Radio Shack / Realistic - AM/FM Stereo Radio/8-Track Tape Player
12-2088.

Sears Silvertone - AM/FM Stereo Receivers 570.74090200/570.74090201.
Sony - AM/FM Stereo Receiver ST-5600.
Zenith - AM/FM Stereo Radio/8-Track Tape Players D680W/D680W1.

Softcover 10 3/4" x 7 3/4". 128 pages.

Price: $16.50

Modular Hi-Fi Components Series.
Volume MHF-56 - Dec. 1974

Covers the following Makes and Models:

Admiral - AM/FM Stereo Radio/Phono/Tape Player Chassis 20G5E.
Arvin - Stereo Phonograph 40P52-18.

Bradford - AM/FM Stereo Radio/4-Channel Tape Player
1404A03 (WTG78022).

Capehart - AM/FM Stereo Radio/8-Track Tape Players N109/N109B.
Craig - AM/FM Stereo Receiver 1506.
Fisher - 4-Channel Tape Player CP-100.
Hitachi - Stereo Amplifier/Mixer 1A-1000.
Magnavox - AM/FM Stereo Radio/Phono/Tape Player Chassis R278.
Panasonic - AM/FM Stereo Receiver SA-60.
Radio Shack / Realistic - Stereo 8-Track Tape Player 14-913.
RCA - AM/FM Stereo Radio/Phonos RK327D/VS5001 (RC1240C).

Sears - AM/FM Stereo Radio/Phono/8-Track Tape Player
171.32731100.

Superscope - AM/FM Stereo Radio/4-Channel Tape Player QRT-440.

Softcover 10 3/4" x 7 3/4". 128 pages.

Price: $16.50

Modular Hi-Fi Components Series.
Volume MHF-79 - Jul. 1976

Covers the following Makes and Models:

J. C. Penney - AM/FM Stereo Radio/Phono/Tape Recorders
1983 (853-3341).

Midland - AM/FM Stereo Radio/Phono/8-Track Tape Players
19-534/19-535.

Panasonic - AM/FM Stereo Radio/8-Track Tape Players
RE-8030/RE-8030C.

Sears - AM/FM Stereo Radio/Phono 132.90410300.
Sherwood - AM/FM Stereo Receivers S-7500/S-8500.
Sony - AM/FM Stereo Radio/Phono HP-170.

Wards Airline - AM/FM Stereo Radio/Phono/Cassette Tape Recorder
GEN-6463A.

Softcover 10 3/4" x 7 3/4". 128 pages.

Price: $16.50

Modular Hi-Fi Components Series.
Volume MHF-83 - Oct. 1976

Covers the following Makes and Models:

Hitachi - AM/FM Stereo Radio/Phono SD-2315.
Lafayette - AM/FM Stereo Radio/Tape Recorder SR-50.
Marantz - AM/FM Stereo Tuner Model 20.
MGA - AM/FM Stereo Radio/Phono SM-15.

Panasonic - AM/FM Stereo Radio/Phono/Tape Recorders
SE-2050/SE-2050C.

Realistic - AM/FM Stereo Radio/Phono/Tape Players
13-1120/13-1121.

Sherwood - AM/FM Stereo Receivers S-8600/S-8600A.
Superscope - AM/FM Stereo Radio/Phono/Tape Player RT-840.

Softcover 10 3/4" x 7 7/8". 128 pages.

Price: $16.50

Modular Hi-Fi Components Series.
Volume MHF-141 - Apr. 1979

Covers the following Makes and Models:

Capehart - AM/FM Stereo Radio/8-Track Tape Player 20X37CA.
Curtis Mathes - AM/FM Stereo Receiver 64-1.

Gran Prix - AM/FM Stereo Radio/Phono/8-Track Tape Recorder
5500.

Hitachi - AM/FM Stereo Tuner FT-440.

Panasonic - AM/FM Stereo Radio/Cassette Tape Recorder
RA-6700.

Sears - AM/FM Stereo Radio/Phono/Cassette Tape Recorder
132.91871700.

Truetone - AM/FM Stereo Radio/Phono/8-Track Tape Player
MJE6800A87.

Softcover 10 3/4" x 7 3/4". 128 pages.

Price: $16.50

Modular Hi-Fi Components Series.
Volume MHF-155 - Aug. 1979

Covers the following Makes and Models:

Fisher - AM/FM Stereo Radio/Cassette Tape Recorder MC-4030.

J. C. Penney - AM/FM Stereo Radio/8-Track Tape Recorder
683-1746-00 (853-1063).

Marantz - AM/FM Stereo Tuners 2020/2050.
Optonica - AM/FM Stereo Receivers SA-5201/SA-5205.
Sharp - AM/FM Stereo Receiver SA-120MKII.
Sherwood - AM/FM Stereo Receiver SA110CP.
Sony - AM/FM Stereo Receiver STR-V4.

Price: $16.50

Modular Hi-Fi Components Series.
Volume MHF-183 - May 1980

Covers the following Makes and Models:

Fisher - AM/FM Stereo Receiver RS-2002.

Lloyd's - AM/FM Stereo Radio/Phono/8-Track Tape Players
BB-9237-205A/DD-9300-0014-205A.

Onkyo - AM/FM Stereo Receiver TX-220.
Optonica - AM/FM Stereo Receivers ST-4401/ST-4405.
Sansui - AM/FM Stereo Receiver TU-719.
Sony - AM/FM Stereo Receiver TA-F60.

Sound Design - AM/FM Stereo Radio/Phono/8-Track Tape Recorders
6557/6947 (65F1/69F11).

Softcover 10 3/4" x 7 3/4". 128 pages.

Price: $16.50
